Asus P8B WS User Manual

5-6 Chapter 5: Multiple GPU technology support
2. Connect either one 8-pin power
connector or two 6-pin power
connectors from the power supply to
the Quadro graphics card and Tesla
computing processor card(s).
3. Connect a display cable to the
graphics card.
4. Refer to the documentation that
came with your graphics card
package to install the device drivers.
5. To verify graphics card driver
installation, right-click My
Computer and select Properties
from the menu. Click the Hardware
tab, and then click Device
Manager. Click the “+” sign before
Display adapters, and the installed
graphics card and computing processor card(s) should appear.
The screen differs based on the components you installed.

Asus P8B WS Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i3
USB 2.0 connectors	8
Number of COM connectors	1
Number of SATA III connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® C206
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Server 2008 Enterprise 32/64-bit, Windows Server 2003 R2 Enterprise 32/64-bit, Windows 7 32/64-bit, Windows Vista 32/64-bit, Windows XP 32/64-bit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1748 MB
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0
LAN controller	Intel® 82574L
Networking features	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	245 mm
Width	305 mm
