Asus P8B WS User Manual

3-20 Chapter 3: BIOS setup
 
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2011 American Megatrends, Inc.
Enabled/Disabled Azalia HD Audio
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
Back Advanced\ Onboard Devices Conguration >
EFI BIOS Utility - Advanced Mode
HD Audio Controller [Enabled]
[Disabled] Disables the controller.
[Enabled] Enables the High Denition Audio Controller.
The following two items appear only when you set the HD Audio Controller
item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or
high-denition audio depending on the audio standard that the front panel audio
module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high
denition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy
AC’97.
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
HD Audio Controller Enabled
Front Panel Type HD
SPDIF Out Type SPDIF
VIA 1394 Controller Enabled
Intel LAN2 Controller Enabled
Intel LAN2 OPROM Enabled
Intel LAN1 Controller Enabled
Intel LAN1 OPROM Enabled
Asmedia USB 3.0 Controller Enabled
Asmedia USB 3.0 Battery Charging Support Disabled
> Serial Port Conguration

Asus P8B WS Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i3
USB 2.0 connectors	8
Number of COM connectors	1
Number of SATA III connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	Intel® C206
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Server 2008 Enterprise 32/64-bit, Windows Server 2003 R2 Enterprise 32/64-bit, Windows 7 32/64-bit, Windows Vista 32/64-bit, Windows XP 32/64-bit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1748 MB
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0
LAN controller	Intel® 82574L
Networking features	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	245 mm
Width	305 mm
