Chapter 2: BIOS information 2-21
2.5.4 System Agent Conguration
Memory Remap Feature [Enabled]
[Enabled] Allow you to enable remapping the memory above 4GB.
[Disabled] Disables this function.
Graphics Conguration
Primary Display [Auto]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [Auto] [iGPU] [PCIE] [PCI]
iGPU Memory [64M]
Allows you to set the iGPU memory size. Conguration options: [Auto] [32M] [64M]
[96M] [128M] ~ [448M] [480M] [512M] [1024M]
Render Standby [Enabled]
Allows you to enable or disable Render Standby by internal graphics devices.
Conguration options: [Enabled] [Disabled]
iGPU Multi-Monitor [Disabled]
Allows you to enable or disable the internal graphics device’s multi-monitor support for
add-on VGA devices. And the memory size for internal graphics device will keep 64MB.
Conguration options: [Disabled] [Enabled]
NB PCIe Conguration
Allows you to congure the NB PCI Express settings.
PCIEX16 Link Speed [Auto]
Allows you to congure the PCIE X16 link speed. Conguration options: [Auto]
[Gen1] [Gen2] [Gen3]
The USB Devices item shows the auto-detected values. If no USB device is detected, the
item shows None.
2.5.5 USB Conguration
The items in this menu allow you to change the USB-related features.
• Due to H61 Chipset limitation, AHCI Mode only works on Windows
®
Vista / Windows
®
7.
Please use IDE Mode on Windows
®
XP.
• [IDE] is the default SATA type. Under Windows
®
XP, there is no need to change the
SATA type.

Asus P8H61-M LX2 R2.0 Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111F
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198.2 mm
Width	244 mm
