Asus P8H61-M PLUS V2 - Motherboard Layout; Layout Contents

1-3Chapter 1: Product introduction
1.2.3 Motherboard layout
1.2.4 Layout contents
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. CPU and chassis fan connectors
(4-pin CPU_FAN, 3-pin CHA_FAN)
1-19 8. Speaker connector (4-pin SPEAKER) 1-21
2. ATX power connectors (24-pin EATXPWR,
4-pin ATX12V)
1-18 9. Clear RTC RAM (3-pin CLRTC) 1-15
3. Serial port connector (10-1 pin COM1) 1-18 10. USB connectors (10-1 pin USB78, USB910) 1-20
4. Intel
®
LGA1155 CPU socket 1-4 11. Digital audio connector (4-1 pin SPDIF_OUT) 1-19
5. DDR3 DIMM slots 1-9 12. Front panel audio connector (10-1 pin AAFP) 1-17
6. Intel
®
H61 Serial ATA 3.0Gb/s connectors
(7-pin SATA3G_1/2/3/4)
1-20 13. Standby power LED (SB_PWR) 1-1
7. System panel connector (10-1 pin PANEL) 1-21
P8H61-M PLUS V2
PCIEX16
PCI1
PCIEX1_1
PCIEX1_2
COM1
USB78 USB910
C
LR
TC
S
P
E
A
K
E
R
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887
RTL
8111E
EPU
32Mb
BIOS
ASM
1083
SB_PWR
SPDIF_OUT
24.4cm(9.6in)
LGA1155
Intel
®
H61
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_3SATA3G_4
SATA3G_1SATA3G_2
AUDIO
KBMS
LAN1_USB12
USB34
20.3cm(8.0in)
VGA
DVI
F_PANEL
321 54 1
6
2
8 710 9111213
