Asus P8H61 USB3 R2.0 User Manual

viii
P8H61 R2.0 Series specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3rd/2nd Generation Core™ i7 / i5 / i3 /
Pentium
®
/ Celeron
®
processors
Supports 22/32nm CPU
Supports Intel
®
Turbo Boost technology 2.0
* The Intel
®
Turbo Boost technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMMs, max. 16GB, DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/
1866(O.C.)/1600/1333/1066 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* DDR3 1600 MHz and higher memory frequency is supported by
Intel
®
3rd generation processors.
** Due to the CPU behavior, DDR3 2133/1866 MHz memory module
will run at DDR3 2000/1800 MHz frequency.
*** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
**** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you
are using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 3.0*/2.0 x16 slot [blue] (at x16 mode)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
* PCIe 3.0 speed is supported by Intel
®
3rd generation Core™
processors.
Storage
Intel
®
H61 Express Chipset:
4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek
®
8111F Gigabit LAN controller
Audio Realtek
®
ALC887 8-channel* High Denition Audio CODEC
* Use a chassis with HD audio module in the front panel to support
an 8-channel audio output.
USB P8H61 R2.0 and P8H61 PLUS R2.0:
Intel
®
H61 Express Chipset:
- 10 x USB 2.0/1.1 ports (6 ports at the mid-board, 4 ports at
the back panel)
P8H61/USB3 R2.0:
ASMedia
®
ASM1042 controller - supports ASUS USB 3.0 Boost
UASP Mode
- 2 x USB 3.0/2.0 ports (at the back panel, blue)
Intel
®
H61 Express Chipset:
- 8 x USB 2.0/1.1 ports (6 ports at the mid-board, 2 ports at the
back panel)

Asus P8H61 USB3 R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA, SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Cables included	SATA
Special features	2 x Thunderbolt
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198.1 mm
Width	305 mm
