2-10 ASUS P8H67-I Series
Pop-up window
Select a menu item and press <Enter> to display a pop-up window with the conguration
options for that item.
Scroll bar
A scroll bar appears on the right side of a menu screen when there are items that do not t on
the screen. Press the Up/Down arrow keys or <Page Up> / <Page Down> keys to display the
other items on the screen.
Navigation keys
At the bottom right corner of the menu screen are the navigation keys for the BIOS setup
program. Use the navigation keys to select items in the menu and change the settings.
General help
At the top right corner of the menu screen is a brief description of the selected item.
Conguration elds
These elds show the values for the menu items. If an item is user-congurable, you can
change the value of the eld opposite the item. You cannot select an item that is not
user-congurable.
A congurable eld is highlighted when selected. To change the value of a eld, select it and
press <Enter> to display a list of options.
2.3 Main menu
The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup
program. The Main menu provides you an overview of the basic system information, and
allows you to set the system date, time, language, and security settings.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
EFI BIOS Utility - Advanced Mode
Choose the system default languageBIOS Information
BIOS Version 0209 x64
Build Date 11/08/2010
ME Version 7.0.0.1135
CPU Information
Genuine Intel(R) CPU 0 @ 3.10GHz
Speed 3100 MHz
Memory Information
Total Memory 2048 MB
Speed 1333 MHz
System Language English
System Date [Mon 09/13/2010]
System Time [16:46:15]
Access Level Administrator
> Security
