Asus P8Z77-V LX User Manual

ix
P8Z77-V LX specications summary
CPU LGA1155 socket for Intel
®
3
rd
/ 2
nd
Generation Core™ i7 / Core™ i5 / Core™
i3 / Pentium
®
/ Celeron
®
processors
Supports 32nm and 22nm CPU
Supports Intel
®
Turbo Boost technology 2.0*
* The Intel
®
Turbo Boost technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Z77 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 2400(O.C.) / 2200(O.C.) / 2133(O.
C.)/1866(O.C.) /1600/1333/1066 MHz, non-ECC, un-buffered memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
*Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL (Qualied Vendors List) for details.
Graphics Integrated Graphics Processor - Intel® HD Graphics Support
Multi-VGA output support: HDMI, DVI, RGB port
- Supports HDMI 1.4a with max.resolution up to 1920 x 1200 @60Hz
- Supports DVI with max. resolution up to 1920 x 1200 @60Hz
- Supports RGB with max. resolution up to 2048 x 1536 @75Hz
- Maximum shared memory of 1696MB
Multi-GPU
support
Supports ATI
®
Quad-GPU CrossFireX
TM
Technology
Expansion
slots
1 x PCI Express 3.0* / 2.0 x16 slot (blue at x16 mode)
1 x PCI Express 2.0 x16 slot (black at x4 mode, compatible with PCIe x1
and x4 devies)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
* PCIe 3.0 speed is supported by Intel
®
3
rd
generation Core
TM
processors.
Storage Intel
®
Z77 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s ports (gray) with RAID 0,1,5,10 support
- 4 x Serial ATA 3.0 Gb/s ports (blue) with RAID 0,1,5,10 support
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, Intel
®
Smart Connect Technology*
*Support for Intel
®
Core
®
processor family with Windows 7 operating
systems.
LAN
Realtek
®
8111E / 8111F Gigabit LAN controller
Audio Realtek
®
ALC887 8-channel* High Denition Audio CODEC
- Supports Jack-Detection, Multi-streaming and Front Panel Jack-
Retasking
- Optical S/PDIF out ports at back I/O
* Use a chassis with HD audio module in the front panel to support an 8-
channel audio output
(continued on the next page)

Asus P8Z77-V LX Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	-
Component for	PC
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Cables included	SATA
LAN controller	Realtek RTL8111E
Wi-Fi standards	Not supported
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	218 mm
Width	305 mm
