P8Z77-V specications summary
(continues on the next page)
CPU LGA1155 socket for Intel
®
3rd/2nd Generation Core™ i7/ i5/ i3/
Pentium
®
/ Celeron
®
Processors
Supports 22/32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel CPU support list
Chipset Intel
®
Z77 Express Chipset
Memory
4 x DIMM, max. 32GB, DDR3 2400(O.C.)*/2200(O.C.)*/2133
(O.C.)/2000(O.C.)/1866(O.C.)/1600/1333/1066 MHz, non-ECC,
un-buffered memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL for details.
Expansion slots
2 x PCI Express 3.0*/2.0 x16 slots (single at 16 or dual at x8 / x8
mode)
1 x PCI Express 2.0 x16 slot** [black] (max. at x4 mode,
compatible with PCIe x1 and x4 devices)
2 x PCI Express 2.0 x1 slots**
2 x PCI slots
* PCIe 3.0 speed is supported by Intel® 3rd generation Core™
processors.
** The PCIe x16_3 slot shares bandwidth with PCIe x1_1 slot,
PCIe x1_2 slot, and SATA6G_E12. The PCIe x16_3 default
setting is in x1 mode.
*** The PCIe x1_2 shares bandwidth with SATA6G_E12.
SATA6G_E12 is enabled by default for system resource
optimization.
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort/HDMI/DVI-D/RGB port
Supports DisplayPort 1.1a with max. resolution 2560 x
1600@60Hz
Supports HDMI 1.4a with max. resolution of 1920 x 1200@ 60Hz
Supports DVI-D with max. resolution 1920 x 1200@60Hz
Supports RGB with max. resolution 2048 x 1536@75Hz
Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD
Technology/Insider™
Multi-GPU support
Supports NVIDIA® Quad-GPU SLI™ Technology (with 2 PCIex16
graphics card)
Supports AMD® 3-Way/ Quad-GPU CrossFireX™ Technology
Supports LucidLogix Virtu MVP Technology*
* LucidLogix Virtu MVP supports Windows 7 operating systems.

Asus P8Z77-V Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400, 2600 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of Parallel ATA connectors	0
Headphone outputs	6
USB 2.0 ports quantity	2
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX, Quad-GPU SLI
PCI Express x16 slots	3
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16, 2x8
Controller 2nd interface type	ASMedia PCIe SATA
Cables included	SATA
LAN controller	Intel® 82579V
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
