Asus ROG STRIX Z690-E GAMING WIFI User Manual

A-2
Appendix
Appendix
Q-Code table
Code Description
E0
S3 Resume is stared (S3 Resume PPI is called by the DXE IPL)
E1
S3 Boot Script execution
E2
Video repost
E3
OS S3 wake vector call
E4 – E7
Reserved for future AMI progress codes
E8
S3 Resume Failed
E9
S3 Resume PPI not Found
EA
S3 Resume Boot Script Error
EB
S3 OS Wake Error
EC – EF
Reserved for future AMI error codes
F0
Recovery condition triggered by firmware (Auto recovery)
F1
Recovery condition triggered by user (Forced recovery)
F2
Recovery process started
F3
Recovery firmware image is found
F4
Recovery firmware image is loaded
F5 – F7
Reserved for future AMI progress codes
F8
Recovery PPI is not available
F9
Recovery capsule is not found
FA
Invalid recovery capsule
FB – FF
Reserved for future AMI error codes
60
DXE Core is started
61
NVRAM initialization
62
Installation of the PCH Runtime Services
63 – 67
CPU DXE initialization is started
68
PCI host bridge initialization
69
System Agent DXE initialization is started
6A
System Agent DXE SMM initialization is started
6B – 6F
System Agent DXE initialization (System Agent module specific)
70
PCH DXE initialization is started
71
PCH DXE SMM initialization is started
72
PCH devices initialization
73 – 77
PCH DXE Initialization (PCH module specific)
78
ACPI module initialization
79
CSM initialization
7A – 7F
Reserved for future AMI DXE codes
(continued on the next page)
This manual downloaded from http://www.manualowl.com

Asus ROG STRIX Z690-E GAMING WIFI Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium G
ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	192 GB
Supported memory clock speeds	6200, 4800, 5000, 5200, 5400, 5600, 5800, 6000 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
USB 2.0 connectors	2
Number of COM connectors	1
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA
Cables included	SATA
Number of M.2 (M) slots	3
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Parallel processing technology support	Not supported
Component for	PC
Product color	Black
Motherboard chipset	Intel Z690
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10, Windows 11
Harmonized System (HS) code	84733020
Weight	1543 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	110 mm
