Asus RT-N12E User Manual

22
RT-N12 LX Chapter 4: Conguring via the web GUI
Setting up the operation mode
The Operation Mode page allows you to set up your wireless router into any of
these two operation modes: IP Sharing mode or Access Point mode.
Setting up the wireless router in IP Sharing mode
In the IP Sharing mode, the wireless router connects to the Internet via PPPoE,
Automatic IP, PPTP, L2TP, or Static IP, and provides you with wireless radio
signals. The NAT, rewall, and IP sharing services for LAN clients are enabled.
To set up the wireless router in IP Sharing mode:
1. From the navigation menu, click Advanced Setting > Administration >
Operation Mode tab.
2. Tick IP Sharing mode (Default) and click Save.
3. Click QIS from the navigation menu. Select your connection type from these
types of ISP services: Automatic IP, PPPoE, Static IP, PPTP, and L2TP.

Asus RT-N12E Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Input current	0.5 A
Rack mounting	-
WLAN data transfer rates supported	1, 2, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Antennas quantity	2
Antenna gain level (max)	2 dBi
Security algorithms	WEP, WPA, WPA2, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product color	Black, Metallic
LED indicators	LAN, Power, WAN

Weight and Dimensions

Depth	168 mm
Width	124 mm
Height	30 mm
Weight	210 g
