Asus TUF Z270 Mark 1 User Manual

ix
CPU
LGA1151 socket for 7th & 6th Generation Intel
®
Core™ i7 / i5 / i3 /
Pentium
®
/Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The support of these features depends on the CPU types.
** Refer to www.asus.com for the complete CPU support list.
Chipset
Intel
®
Z270 Chipset
Memory
4 x DIMM, max. 64GB DDR4 3866(O.C.) / 3733(O.C.) / 3600(O.C.) /
3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.)
/ 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz
Non-ECC, Un-buffered Memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)*
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL (Qualified Vendors List)
for details.
**
Refer to www.asus.com for the complete Memory QVL (Qualified
Vendors List).
Expansion slots
2 x PCI Express 3.0/2.0 x16 slots (single at x16 or dual at x8/x8
mode)
1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode, compatible with
PCIe x1, x2 and x4 devices)
3 x PCI Express 3.0/2.0 x1 slots
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort/HDMI port
Supports DisplayPort 1.2* with max. resolution 4096 x 2304@60Hz
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD
Technology/Insider™
Maximum shared memory of 1024MB
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor
daisy chain up to 3 displays
Multi-GPU support
Supports NVIDIA
®
2-Way/Quad-GPU SLI
®
Technology
Supports AMD
®
3-Way/Quad-GPU CrossFireX™ Technology
LAN
Gigabit Intel LAN connection- 802.3az Energy Efcient Ethernet
(EEE) appliance
Intel
®
I219-V Gigabit LAN - Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Intel
®
I211 Gigabit LAN controller
TUF LANGuard
ASUS Turbo LAN Utility
(continued on the next page)
TUF Z270 MARK 1 specifications summary

Asus TUF Z270 Mark 1 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3733, 3866 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	2
Number of SATA III connectors	6
Number of EATX power connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Motherboard chipset	Intel® Z270
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64
LAN controller	Intel I211, Intel I219V
Ethernet interface type	Gigabit Ethernet
Number of displays supported	3
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
