3-11
Chapter 3: General Instruction
3.4 Supported Timing List
VESA / IBM Modes Support Timing
Mode
Resolution
(active dot)
Resolution
(total dot)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Nominal Pixel
Color (MHz)
VGA
640x480@60Hz 800 x 525 31.469 59.940 25.175
800x600@60Hz 1056 x 628 37.879 60.317 40.000
XGA 1024x768@60Hz 1344x806 48.363 60.004 65.000
SXGA
1280x1024@60Hz 1688x1066 63.981 60.020 108.000
1280x960@60Hz 1800x1000 60.000 60.000 108.00
WXGA
1280x800@60Hz 1680x831 49.702 59.810 83.500
1280x720@60Hz 1650x750 45.00 60.000 74.25
1280x768@60Hz 1664x798 47.776 59.870 79.5
1360x768@60Hz 1792x795 47.712 60.015 85.500
1366x768@60Hz 1792x798 47.712 59.790 85.500
WXGA+ 1440x900@60Hz 1904x934 55.935 59.887 106.500
UXGA 1600x1200@60Hz 2160x1250 75.000 60.000 162.000
WSXGA+ 1680x1050@60Hz 2240x1089 65.290 59.954 146.250
WUXGA
1920x1080@60Hz 2576x1120 67.158 59.963 173.000
1920x1080@60Hz 2200x1125 67.500 60.000 148.500
1920x1080@60Hz 2080x1111 66.587 59.934 138.500
* Modes not listed in the table may not be supported. For optimal resolution, we recommend that
you choose a mode listed in the table above.
*
Do not support interlaced video 480i/1080i, the recomendation timing is progressive 480p/1080p
