2-1
ASUS LCD Monitor VG2
49
Series
2.1 Detaching the arm/stand (for VESA wall
mount)
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the front of the
monitor face down on a clean table.
2. Use a screwdriver to remove the four screws on the arm (Figure 1),
and then detach the arm/stand from the monitor (Figure 2).
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the stand of the monitor while removing the screws.
Figure 1 Figure 2
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load 12 kg
(Screw size: M4 x 10 mm).
