Asus VS228T-P User Manual

3-8
ASUS LCD monitor VS228T-P
3.4 Supported Timing List
VESA / IBM Modes Support Timing (D-SUB, DVI-D inputs)
Resolution Refresh Rate Horizontal Frequency
640x350 70Hz 31.469KHz
640x480 60Hz 31.469KHz
640x480 67Hz 35KHz
640x480 75Hz 37.5KHz
720x400 70Hz 31.469KHz
800x600 56Hz 35.156KHz
800x600 60Hz 37.879KHz
800x600 72Hz 48.077KHz
800x600 75Hz 46.875KHz
848x480 60Hz 31.02KHz
1024x768 60Hz 48.363KHz
1024x768 70Hz 56.476KHz
1024x768 75Hz 60.023KHz
1152x864 75Hz 67.5KHz
1280x720 60Hz 44.772KHz
1280x800 60Hz 49.702KHz
1280x960 60Hz 60KHz
1280x1024 60Hz 63.981KHz
1280x1024 75Hz 79.976KHz
1366x768 60Hz 47.712KHz
1440x900 60Hz 55.935KHz
1680x1050 60Hz 65.29KHz
1680x1050 60Hz 64.674KHz
1920x1080 60Hz 67.5KHz
1920x1080 60Hz 66.587KHz
* The modes not listed in the above tables may not be supported. For optimal resolution, we
recommend that you choose a mode listed in the above tables.

Asus VS228T-P Specifications

General

Panel Size	21.5”W(54.6 cm)
Max. Resolution	1920 x 1080 (FHD)
Backlight Tech.	LED Backlight Technology
Brightness (Typ.)	250cd/m2
Intrisinc Contrast Ratio (Typ.)	1000:1
Viewing Angle (CR=10)	≧170°(H) / ≧160°(V)
Display Colors	16.7 M
Response Time	5 ms
Audio input	Yes
DVI input	Yes
D-Sub input	Yes
Power Consumption	Power ON < 21.1W*
Power Saving Mode	< 0.5 W
Power OFF Mode	< 0.5 W
Voltage Rating	AC 100~240V(Built-in)
Note	* Based on Energy Star 6.0 standard
Tilt	-5° ~ +20°
VESA Wall Mounting	Yes (100mm x 100mm)

Weight and Dimensions

Phys. Dimension (WxHxD)	514 x 386 x 200 mm
Box Dimension (WxHxD)	566 x 443 x 130 mm
Net Weight (Esti.)	3.2 kg
Gross Weight (Esti.)	5.3 kg
