2-2 Chapter 2: Setup
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• The recommended adjusting angle is +22˚ to -5˚ (for tilt)/+160˚ to -160˚ (for
swiveling/ +110 mm (for height adjustment)/90˚ (for portrait view).
160˚ 160˚
0˚
+22˚~-5˚
1. Lift the monitor to the highest position.
2 Tilt the monitor to its maximum angle.
3. Pivot the monitor clockwise to the angle you need.
+22˚~-5˚
It is normal that the monitor slightly shakes while you adjust the viewing angle.
(Tilt) (Swivel) (Height adjustment)
