Asus VW197DR User Manual

1-6 Chapter 1: Product Introduction
1.4.3 WiringtocomplywithTCOCertied(VW197TR/
VW197NR/VW197SR/VW197DR)
1. Connect the power cord and signal cable.
2. Tie the power cord and signal cable with cable holder.
• The location of holder should be about 10cm away from one end of the
power cord and cable.
10cm

Asus VW197DR Specifications

General

Panel Size	18.5”W (47.0cm)
Max. Resolution	1366x768
Backlight Tech.	LED Backlight Technology
Brightness (Typ.)	250cd/㎡
Intrinsic Contrast Ratio (Typ.)	1000:1
Display Colors	16.7 M
Response Time	5ms (Tr+Tf)
Viewing Angle (H/V), (CR≥10)	170°/160°
Analog Input	D-Sub
Digital Input	DVI(VW197T/TR/N/NR only)
Speaker (Build-in)	1W x 2 (VW197T/TR/S/SR only)
Tilt	-5° ~ +20°
VESA Wall Mounting	Yes (100mm x 100mm)
Voltage Rating	AC 100~240V(Built-in)

Weight and Dimensions

Phys. Dimension (WxHxD)	445x370x185mm
Box Dimension (WxHxD)	507x150x322mm
Net Weight (Esti.)	3.1 kg
Gross Weight (Esti.)	4.9 kg
