Asus VW197DR User Manual

2-2 Chapter 2: Setup
2.2. Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling while changing its angle.
• Youcanadjustthemonitor’sanglefrom-5˚to20˚.
-5 ~ 20

Asus VW197DR Specifications

General

Panel Size	18.5”W (47.0cm)
Max. Resolution	1366x768
Backlight Tech.	LED Backlight Technology
Brightness (Typ.)	250cd/㎡
Intrinsic Contrast Ratio (Typ.)	1000:1
Display Colors	16.7 M
Response Time	5ms (Tr+Tf)
Viewing Angle (H/V), (CR≥10)	170°/160°
Analog Input	D-Sub
Digital Input	DVI(VW197T/TR/N/NR only)
Speaker (Build-in)	1W x 2 (VW197T/TR/S/SR only)
Tilt	-5° ~ +20°
VESA Wall Mounting	Yes (100mm x 100mm)
Voltage Rating	AC 100~240V(Built-in)

Weight and Dimensions

Phys. Dimension (WxHxD)	445x370x185mm
Box Dimension (WxHxD)	507x150x322mm
Net Weight (Esti.)	3.1 kg
Gross Weight (Esti.)	4.9 kg
