Asus VW199T User Manual

1-5ASUSLEDMonitorVW199Series
6. Power Indicator
• The color definition of the power indicator is as the below table.
Status Description
Blue ON
Amber Standby mode
OFF OFF
1.4.2 Rear of the LED monitor
Rear connectors
Screw holes for
VESA Wall Mount
4
3
2
1
1 AC-IN port
2 Audio Line-in port (VW199T/S)
3 DVI port (VW199T/N)
4 VGA port

Asus VW199T Specifications

General

Panel Size	19”W (48.3 cm)
Max. Resolution	1440x900
Brightness (Typ.)	250cd/m2
Intrisinc Contrast Ratio (Typ.)	1000:1
Display Colors	16.7 M
Viewing Angle (H/V), (CR≥10)	170°/160°
Response Time	5ms (Tr+Tf)
Analog Input	D-Sub
Digital Input	DVI(VW199T/N only)
Speaker (Build-in)	1W x 2 (VW199T/ S only)
Voltage Rating	AC 100~240V(Built-in)

Weight and Dimensions

Tilt	-5° ~ +20°
VESA Wall Mounting	Yes (100 mm x 100 mm)
Phys. Dimension (WxHxD)	444x369.26x210 mm
Box Dimension (WxHxD)	496x416x139 mm
Net Weight (Esti.)	4.0 kg
Gross Weight (Esti.)	5.2 kg
