Asus X99-M WS User Manual

ix
(continued on the next page)
X99-M WS specications summary
CPU
LGA2011-v3 socket for Intel
®
Core™ i7/Xeon
®
E5-2600/1600 v3
processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU
types.
Chipset
Intel
®
X99 Express Chipset
Memory
4 x DIMM, Max. 64 GB, DDR4 3200 (O.C.)* / 2800 (O.C.)* / 2666
(O.C.)* / 2400 (O.C.)* / 2133 MHz, non-ECC, unbuffered memory
(When installing Intel
®
Socket 2011-v3 Core™ i7 processors)
4 x DIMM, Max. 64 GB, DDR4 2133 MHz ECC, unbuffered memory
(When installing Intel
®
Xeon™ E5-1600 v3 / 2600 v3 processors)
4 x DIMM, Max. 64 GB, DDR4 2133 MHz ECC, register memory
(When installing Intel
®
Xeon™ E5-1600 v3 / 2600 v3 processors)
Quad channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Refer to memory QVL (Qualied Vendors Lists) for
details.
Expansion slots
3 x PCI Express 3.0/2.0 x16 Slots (40-Lane CPU: x16, x16/x16, x16/
x16/x8 Mode; 28-Lane CPU: x16, x16/x8, x16/x8/x4 Mode)
1 x PCI Express 2.0 x1 slot
Multi-GPU support
Supports AMD
®
2-Way CrossFireX™ Technology
Supports NVIDIA
®
2-Way SLI™ Technology
Storage
Intel
®
X99 Express Chipset with RAID 0, 1, 5, 10 and Intel
®
Rapid Storage Technology 13 support
- 8 x SATA 6.0 Gb/s ports
- 1 x M.2 Socket 3 with M Key, Type 2260/2280 Storage Devices
Support (SATA/PCIE mode)
- Supports Intel
®
Smart Response Technology**
** These functions will work depending on the CPU installed.
LAN
1 x Intel
®
I210-AT Gigabit LAN controller
1 x Intel
®
I218-LM Gigabit LAN- Dual Interconnect between the
Integrated LAN Controller and Physical Layer (PHY)
Wireless data network
Wi-Fi 802.11a/b/g/n/ac, supports dual band frequency 2.4/5 GHz
Supports ASUS Wi-Fi Go! utility
Up to 1300Mbps transfer speed
Bluetooth Bluetooth V4.0
Audio
Realtek
®
ALC1150 8-channel high denition audio CODEC featuring
Crystal Sound 2
- Separate Layer for Left and Right Track, Ensuring Both Sound
Deliver Equal Quality
- Audio Shielding Ensures Precision Analog/Digital Separation and
Greatly Reduced Multi-lateral Interference
- Audio Amplier to Enhance the Highest Quality Sound for
Headphone and Speakers

Asus X99-M WS Specifications

General

Non-ECC	Yes
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2666, 2800, 2133, 3000, 2400, 3200 MHz
Processor socket	LGA 2011-v3
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	8
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	16 Mbit
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel I218-LM, Intel I210-AT
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC1150
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® X99
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Parallel processing technology support	2-Way SLI, Quad-GPU SLI, 2-Way CrossFireX, Quad-GPU CrossFireX
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Cables included	USB, SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	244 mm
