ASUS Z170-E Series
1-23
• The plugged USB 3.0 device will run on xHCI mode.
• USB 3.0 devices can only be used for data storage.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance from your USB 3.0 devices.
• Due to the design of the Intel
®
chipset, all USB devices connected to the USB 2.0 and
USB 3.0 ports are controlled by the xHCI controller. Some legacy USB devices must
update their rmware for better compatibility.
• Multi-VGA output supports up to three displays under Windows
®
OS environment, two
displays under BIOS, and one display under DOS.
• Intel display architecture design supports the following maximum supported pixel
clocks (Pixel Clock = H total x V Total x Frame Rate (Screen refresh rate):
- DVI port: 148 MHz
- HDMI port: 300 MHz
* LAN ports LED indications
ACT/LINK
LED
SPEED
LED
LAN port
Activity Link LED Speed LED
Status Description Status Description
Off
No link Off 10 Mbps connection
Orange
Linked Orange 100 Mbps connection
Orange (Blinking)
Data activity Green 1 Gbps connection
Orange (Blinking
then steady)
Ready to wake up
from S5 mode
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
Light Blue Line In Line In Line In Side Speaker Out
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Gray – – – Side Speaker Out
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
** Audio 2.1, 4.1, 5.1, or 7.1-channel configuration

Asus Z170-E Specifications

General

Chipset	Intel Z170
Socket	LGA 1151
Form Factor	ATX
Memory Slots	4
Memory Type	DDR4
Maximum Memory	64 GB
Memory Speed	DDR4 3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz
PCI Express x16 Slots	2
PCI Express x1 Slots	3
SATA Ports	6 x SATA 6Gb/s
M.2 Slots	1
USB 3.0 (Gen 1)	6
USB 2.0	6
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Intel I219V, 1 x Gigabit LAN Controller(s)
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD CrossFireX
USB 3.1 (Gen 2)	2 (1 x Type-A + 1 x Type-C)
