2-28
ASUS Z87-C
PCIe Speed [Auto]
Allows you to select the PCI Express port speed.
Conguration options: [Auto] [Gen1] [Gen2]
Intel(R) Rapid Start Technology [Disabled]
Allows your computer to quickly resume from slow-power hibernate state in seconds. Saving
your system memory to the designated SSD, it provides your computer a faster wake-up
response time, while still keeping the energy use low.
Conguration options: [Enabled] [Disabled]
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S3 mode.
Conguration options: [Enabled] [Disabled
Entry After [0]
Allows you to set the RTC wake-up timer at S3 entry. The time ranges from
0 minute (immediately) to 120 minutes.
Active Page Threshold Support [Enabled]
The system automatically goes into sleep mode when the partition size is not enough
for the Intel
®
Rapid Start Technology to work.
Conguration options: [Enabled] [Disabled]
Active Memory Threshold [0]
This item supports Intel Rapid Storage Technology when the partition size
is greater than the Active Page Threshold size. When set to zero (0), it will
go to Auto mode and checks if the partition size is enough at S3 entry.
Ensure that the caching partition size is larger than the total memory size.
Hybrid Hard Disk Support [Disabled]
Allows you to enable or disable the hybrid hard disk support.
Conguration options: [Enabled] [Disabled]
Intel(R) Smart Connect Technology
ISCT Support [Disabled]
Allow you to enable or disable the Intel
®
Smart Connect Technology.
Conguration options: [Enabled] [Disabled]
2.6.3 SATA Conguration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Not Present if no SATA device is installed to the corresponding SATA
port.
