Instruction book
Tank-mounted, vertical receiver
Tank-mounted, horizontal receiver
Reference
Description
1
Compressor
2
Pressure relief valve
3
Air outlet valve
4
Hour meter (option)
5
Electric cabinet
6
On/off switch
7
Air receiver
8
Air pressure switch
9
Air pressure gauge
10
Compressor
11
Condensate drain valve
