9 Technical data
9.1 Reference conditions and limitations
Reference conditions
Unit
Value
Compressed air effective inlet
pressure
bar 7
Ambient air temperature °C 25
Compressed air inlet
temperature
°C 35
Inlet relative humidity % 100
Pressure dewpoint °C 7
Atmospheric dewpoint °C -18
Limitations for operations
Unit Value
Maximum compressed air
effective inlet pressure
bar 13
(1)
Maximum ambient temperature °C 46
Minimum ambient temperature °C 5
Maximum compressed air inlet
temperature
°C 62
Unit Value
Maximum compressed air
effective inlet pressure
bar 16
(1)
Maximum ambient temperature °C 46
Minimum ambient temperature °C 5
Maximum compressed air inlet
temperature
°C 62
(1) Please check name plate for the working pressure (located at the rear side)
9.2 Air dryer data
Performance data
Unit
F6 F11 F18 F25 F35
Volume flow at
dryer inlet
l/s 6 11 18 25 35
Pressure drop
over dryer
bar 0.28 0.28 0.28 0.28 0.28
Instruction book
2920 7210 40 31
