3 Installation
3.1 Dimension drawings
The dimension drawings can be found on the CD-ROM, delivered with the dryer.
Dimension drawing Model
2202 7549 00 FX 1 up to FX 5
2202 7463 00 FX 6 and FX 7
2202 7464 00 FX 8 up to FX 10
2202 7465 00 FX 11 and FX 12
Text on drawings Translation or explanation
Electric cable outlet
Outlet for electric cable
Condensate pipe drain outlet
Outlet for condensate drain hose or pipe
Air inlet
Air inlet
Air outlet
Air outlet
Air flow
Air flow direction
Bushings UL version only
Bushings (UL certification version only)
Female
Female connection
Male
Male connection
All dimensions: mm / inch
All dimensions are in mm or inch as indicated on the
drawing
3.2 Installation proposal
Moving
Use a suitable tool (pallet carrier, fork lift truck) to move the dryer.
Do not use metal cables for lifting.
Move the dryer gently.
Instruction book
14 2920 7112 40
