Icon Name Mode Function
Flashing + H3 Too high discharge
temperature of the
refrigerant compressor
(see further)
Dryer is stopped
Fan Off Fan off
Flashing Not applicable
On Fan on
Remote alarm function
Depending on the dryer model, the controller allows to remotely control a number of alarms. This is
managed by means of a free NC (Normally Closed) contact.
The contact opens in case of an alarm or when the dryer is switched off.
Refer to the table below to identify the availability of the function and refer to the related picture to identify
the physical location of the free contact.
Availability of the remote alarm function
Model Fault message availability
P1 P2 P3 L2 H2 H3
FX 1 to FX 3 no yes no yes yes no
FX 4 and FX 5 yes yes no yes yes no
FX 6 to FX 12 yes yes yes yes yes yes
Location of the free contact (1)
Instruction book
2920 7112 40 19
