User manual
Unloading/loading pressures for GA Workplace Full-Feature with ICD
Dewpoint -40° variant 50Hz
Combination UNLOADING LOADING
GA and ICD
GA Model ICD model Minimum Nominal Maximum Minimum Nominal Maximum
Unloading Unloading Unloading Loading Loading Loading
Pressure Pressure Pressure Pressure Pressure Pressure
bar bar bar bar bar bar
GA30 - 7.5 CD100 6.5 6.9 6.9 6.4 6.4 6.8
GA30 - 7.5 CD140 5.4 6.5 6.8 5.3 6.0 6.7
GA30 - 7.5 CD170 4.8 6.5 6.8 4.7 6.0 6.7
GA30 - 8 CD100 6.4 7.0 7.3 6.3 6.5 7.2
GA30 - 8 CD140 5.2 7.0 7.3 5.1 6.5 7.2
GA30 - 8 CD170 4.6 7.0 7.3 4.5 6.5 7.2
GA30 - 10 CD100 5.9 9.0 9.3 5.8 8.5 9.2
GA30 - 10 CD140 4.8 9.0 9.3 4.7 8.5 9.2
GA30 - 10 CD170 4.3 9.0 9.3 4.2 8.5 9.2
GA30 - 13 CD100 8.7 12.0 12.3 8.6 11.5 12.2
GA30 - 13 CD140 7.1 12.0 12.3 7.0 11.5 12.2
GA30 - 13 CD170 6.4 12.0 12.3 6.3 11.5 12.2
GA37 - 7.5 CD140 6.1 6.5 6.8 6.0 6.0 6.7
GA37 - 7.5 CD170 5.4 6.5 6.8 5.3 6.0 6.7
GA37 - 8 CD140 5.9 7.0 7.3 5.8 6.5 7.2
GA37 - 8 CD170 5.3 7.0 7.3 5.2 6.5 7.2
GA37 - 10 CD100 6.8 9.0 9.3 6.7 8.5 9.2
GA37 - 10 CD140 5.5 9.0 9.3 5.4 8.5 9.2
GA37 - 10 CD170 4.9 9.0 9.3 4.8 8.5 9.2
GA37 - 13 CD100 9.7 12.0 12.3 9.6 11.5 12.2
GA37 - 13 CD140 8.0 12.0 12.3 7.9 11.5 12.2
GA37 - 13 CD170 7.1 12.0 12.3 7.0 11.5 12.2
GA45 - 7.5 CD170 6.0 6.5 6.8 5.9 6.0 6.7
GA45 - 8 CD140 6.3 7.0 7.3 6.2 6.5 7.2
GA45 - 8 CD170 5.6 7.0 7.3 5.5 6.5 7.2
GA45 - 10 CD100 8.5 9.0 9.3 8.4 8.5 9.2
GA45 - 10 CD140 6.3 9.0 9.3 6.2 8.5 9.2
GA45 - 10 CD170 5.6 9.0 9.3 5.5 8.5 9.2
GA45 - 13 CD100 11.2 12.0 12.3 11.1 11.5 12.2
GA45 - 13 CD140 9.2 12.0 12.3 9.1 11.5 12.2
GA45 - 13 CD170 8.2 12.0 12.3 8.1 11.5 12.2
GA55C - 7.5 CD170 6.5 6.9 6.9 6.4 6.4 6.8
GA55C - 10 CD140 6.9 9.0 9.3 6.8 8.5 9.2
GA55C - 10 CD170 6.1 9.0 9.3 6.0 8.5 9.2
GA55C - 13 CD140 10.2 12.0 12.3 10.1 11.5 12.2
GA55C - 13 CD170 9.2 12.0 12.3 9.1 11.5 12.2
GA55 - 7.5 CD230 5.8 6.5 6.8 5.7 6.0 6.7
GA55 - 7.5 CD280 5.1 6.5 6.8 5.0 6.0 6.7
GA55 - 8 CD170 6.6 7.0 7.3 6.5 6.5 7.2
GA55 - 8 CD230 5.6 7.0 7.3 5.5 6.5 7.2
GA55 - 8 CD280 5.0 7.0 7.3 4.9 6.5 7.2
GA55 - 10 CD170 6.2 9.0 9.3 6.1 8.5 9.2
GA55 - 10 CD230 5.2 9.0 9.3 5.1 8.5 9.2
GA55 - 10 CD280 4.6 9.0 9.3 4.5 8.5 9.2
