Atlas Copco GA37 User Manual

2920 1461 03
18
User manual
Compr Outlet
bar 7.0
Auto Loaded
↓
Menu Unld
Auto Operation
Local Control
Timer Active
↓
Main Help Xtra
Max Pressure
↑
bar 7.5
↓
Main Help Xtra
Status data
→
Measured data
Counters ↓
Main
All Conditions
Are OK
Menu
Status data
↑
Measured data →
Counters ↓
Main
Compr Outlet
Bar 7.0
↓
Menu Xtra
Measured data
↑
Counters →
Test ↓
Main
Counters
↑
Test →
Modify Params ↓
Main
Test
↑
Modify Params →
Service ↓
Main
Modify Params
↑
Service →
Saved data ↓
Main
Running hours
hrs 2107
↓
Menu
Parameters
→
Protections
Service Plan
↓
Menu
Loading Press
Bar 6.4
↓
Menu Mod
Parameters
↑
Protections →
Service Plan ↓
Menu
Compr Outlet
Bar 6.8
↓
Menu
Protections
↑
Service Plan →
Clock Function ↓
Menu
Service Timer
Running hours →
hrs 130 ↓
Menu
Service Timer
Running hours
→
hrs 130 ↓
Menu
Modify Params
↑
Service
Saved data
→
Main
Last Shutdown 1
→
Last Shutdown 2
Last Shutdown 3
↓
Menu
52948PEN
Service Plan ↑
Clock Function →
Configuration ↓
Menu
Clock Function
Not Activated
→
Menu Mod Del
Service Plan ↑
Clock Function
Configuration
→
Menu
Time
10:54
↓
Menu Mod
-Running Hours
-Loaded Hours
-Motor Starts
-Module Hours
-Load Relay
-Compr Outlet
-DP Oil Separ
-Element Outlet
-Dryer LAT
-Emergency Stop
-Rem Start/Stop
-Rem Load/Unl
-Rem Pressure
-Overload Motor
-Overl Fanmotor
-P1 open/P2 closed
-DP Oil Separ
-Element Outlet
-Dryer LAT
-Emergency Stop
-Rem Start/Stop
-Rem Load/Unl
-Rem Pressure
-Overload Motor
-Overl Fanmotor
-P1 open/P2 closed
-Loaded Hours
-Motor Starts
-Module Hours
-Load Relay
-Unloading Press
-Loading Press 2
-Unloading Press 2
-Y-Time
-Load delay
-Nr Starts/Day
-Min Stop Time
-Progr Stop Time
-Commun Time-out
Display test →
Safety valve
↓
Menu
-DP Oil separ
-Element outlet
-Dryer LAT
-Emergency Stop
-Rem Start/Stop
-Rem Load/Unl
-Rem Pressure
-Overload Motor
-Overl Fanmotor
-P1 open/P2 closed
-Date
-Date format
-Language in use
-Pressure Unit
-Temperat Unit
-Vibration Unit
-Level Unit
-Pres Band Used
-Start Mode
-CCM (control mode)
-Auto Restart
-Password
-Node ID
-MCC
-Digital PB Sel
Fig. 3.1a Simplified menu flow of GA Workplace Full-Feature with IFD
