Atlas Copco GA5 User Manual

2920 1461 03
36
User manual
Dewpoint -70° variant 60Hz
Combination UNLOADING LOADING
GA and ICD
GA Model ICD model Minimum Nominal Maximum Minimum Nominal Maximum
Unloading Unloading Unloading Loading Loading Loading
Pressure Pressure Pressure Pressure Pressure Pressure
bar bar bar bar bar bar
GA30 - 100 CD140 6.1 6.5 6.7 6.0 6.0 6.6
GA30 - 100 CD170 5.5 6.4 6.7 5.4 5.9 6.6
GA30 - 125 CD100 7.4 8.1 8.4 7.3 7.6 8.3
GA30 - 125 CD140 5.8 8.1 8.4 5.7 7.6 8.3
GA30 - 125 CD170 5.2 8.1 8.4 5.1 7.6 8.3
GA30 - 150 CD100 6.4 9.8 10.1 6.3 9.3 10.0
GA30 - 150 CD140 5.3 9.8 10.1 5.2 9.3 10.0
GA30 - 150 CD170 4.7 9.8 10.1 4.6 9.3 10.0
GA30 - 175 CD100 10.0 11.5 11.8 9.9 11.0 11.7
GA30 - 175 CD140 8.3 11.5 11.8 8.2 11.0 11.7
GA30 - 175 CD170 7.4 11.5 11.8 7.3 11.0 11.7
GA37 - 100 CD170 6.2 6.6 6.7 6.1 6.1 6.6
GA37 - 125 CD140 6.6 8.1 8.4 6.5 7.6 8.3
GA37 - 125 CD170 5.8 8.1 8.4 5.7 7.6 8.3
GA37 - 150 CD100 8.2 9.8 10.1 8.1 9.3 10.0
GA37 - 150 CD140 6.1 9.8 10.1 6.0 9.3 10.0
GA37 - 150 CD170 5.5 9.8 10.1 5.4 9.3 10.0
GA37 - 175 CD100 11.4 11.8 11.8 11.3 11.3 11.7
GA37 - 175 CD140 9.4 11.5 11.8 9.3 11.0 11.7
GA37 - 175 CD170 8.4 11.5 11.8 8.3 11.0 11.7
GA45 - 125 CD140 7.8 8.2 8.4 7.7 7.7 8.3
GA45 - 125 CD170 6.6 8.1 8.4 6.5 7.6 8.3
GA45 - 150 CD140 7.0 9.8 10.1 6.9 9.3 10.0
GA45 - 150 CD170 6.2 9.8 10.1 6.1 9.3 10.0
GA45 - 175 CD140 10.5 11.5 11.8 10.4 11.0 11.7
GA45 - 175 CD170 9.4 11.5 11.8 9.3 11.0 11.7
GA55C - 125 CD170 7.3 8.1 8.4 7.2 7.6 8.3
GA55C - 150 CD140 8.3 9.8 10.1 8.2 9.3 10.0
GA55C - 150 CD170 6.7 9.8 10.1 6.6 9.3 10.0
GA55C - 175 CD170 10.6 11.5 11.8 10.5 11.0 11.7
GA55 - 100 CD280 5.9 6.4 6.7 5.8 5.9 6.6
GA55 - 125 CD170 7.8 8.2 8.4 7.7 7.7 8.3
GA55 - 125 CD230 6.1 8.1 8.4 6.0 7.6 8.3
GA55 - 125 CD280 5.5 8.1 8.4 5.4 7.6 8.3
GA75 - 125 CD230 7.9 8.3 8.4 7.8 7.8 8.3
GA75 - 125 CD280 6.6 8.1 8.4 6.5 7.6 8.3
GA75 - 150 CD230 7.1 9.8 10.1 7.0 9.3 10.0
GA75 - 150 CD280 6.2 9.8 10.1 6.1 9.3 10.0
GA75 - 175 CD230 10.7 11.5 11.8 10.6 11.0 11.7
GA75 - 175 CD280 9.6 11.5 11.8 9.5 11.0 11.7
GA90C - 125 CD280 7.2 8.1 8.4 7.1 7.6 8.3
GA90C - 150 CD230 8.2 9.8 10.1 8.1 9.3 10.0
GA90C - 150 CD280 6.7 9.8 10.1 6.6 9.3 10.0
GA90C - 175 CD230 11.4 11.8 11.8 11.3 11.3 11.7
GA90C - 175 CD280 10.3 11.5 11.8 10.2 11.0 11.7
