Atlas Copco LF 2 User Manual

2920 7090 00 61
Instruction book
8 Technical data
8.1 Reference conditions
Inlet pressure (absolute)
bar 1
Relative air humidity % 0
Air inlet temperature ºC 20
Working pressure:
for LF 10 bar bar(e) 7
8.2 Limitations
Minimum inlet temperature
°C 0
Maximum inlet temperature ºC 40
Maximum working pressure bar(e) See below
Only applicable for Full Feature variants. (with refrigerant dryer)
Minimum ambient air temperature °C 5
8.3 Compressor data
50 Hz (10 bar)
Compressor
type
LF 2 LF 3 LF 5 LF 7 LF 10
Maximum
working
pressure
bar(e) 10 10 10 10 10
Maximum
working
pressure for
Trolley
bar(e) 9.5 9.5 9.5 9.5 9.5
Pre-set
pressure
difference for
Trolley
bar 1 1 1 1 1
Temperature at outlet valve, approx.
- Unsilenced
compressor
ºC 40 44 45 50 51
- Silenced
compressor
ºC 48 52 53 58 59
Power input at
maximum
working
pressure
kw 2.05 2.71 5.11 5.89 8.65
