7 Technical data
7.1
Reference conditions and limitations
Reference conditions
Effective working pressure of the
compressor
bar(e) 7
Compressor running hours per day h 12
Oil type Roto-Inject Fluid, Roto-Xtend Duty Fluid, Roto-
Foodgrade Fluid
Compressor type All types of GA oil injected compressors
The reference conditions for the OSC distinguish 3 climate types:
•
Cold climate: ambient temperature of 15 °C (59 °F) and relative humidity of 60 %
• Mild climate: ambient temperature of 25 °C (77 ºF) and relative humidity of 60%
• Hot climate: ambient temperature of 35 °C (95 ºF) and relative humidity of 70%
Limitations for operation
Minimum inlet temperature ˚C 1
Minimum ambient temperature ˚C 1
Maximum condensate inlet temperature ˚C 75
Maximum oil content at outlet of the OSC mg/l 15
Note: maximum oil flow rate 10.5 g/h (0.37 oz/h)
7.2
Technical data
Compressor FAD
For poly-glycol based condensates, the capacity of each unit should be
halved.
Installation with compressors, air receivers, filters and dryers:
Models OSC
145
Cold climate l/s 65 180 270 665 1150 1550 2220 4440
Mild climate l/s 35 95 145 355 605 825 1180 2360
Hot climate l/s 17 45 70 170 290 400 570 1145
Installation with compressors, air receivers and filters:
Instruction book
AIF999999 23
