Atlas Copco ZT 110 User Manual

6.15 Outputs menu
Control panel
(1) Enter key
(2) Escape key
(3) Scroll keys
Menu icon, Outputs
Function
To display information regarding the current status of the digital outputs.
Procedure
Starting from the Main screen (see Main screen),
• Move the cursor to the Menu action button and push the Enter key. Following screen appears:
Instruction book
2920 1815 04 155

Atlas Copco ZT 110 Specifications

General

Model	ZT 110
Type	Oil-free rotary screw compressor
Flow rate	10.5 m³/min
Air quality	Class 0
Free Air Delivery	10.5 m³/min
