AA60 MIXER AMPLIFIER
SPECIFICATIONS
POWER OUTPUT
Max. Average Power @ 50 Hz-20 kHz with .5% THD (10-80 kHz filter)
8Ω, 1 kHz, 0.5% THD 60 watt RMS
TRANSFORMER OUTPUTS
25V 60 watt RMS into 10.4Ω
70.7V 60 watt RMS into 83.3Ω
4Ω 60 watt RMS
FREQUENCY RESPONSE
50 Hz - 20 kHz
THD+N
.5% or less, at 1 kHz, rated output
.1% or less, at 1 kHz, 5 watt output
SENSITIVITY
Input 1 Mic .316 ~ 3.16mV (-50 ~ -30 dBV)
Input 1 Telephone/Line 316mV (-10 dBV) 600Ω (optional 600Ω transformer available)
Input 2/3 316mV (10 dBV) 10kΩ
OUTPUTS
Main: Transformer coupled, balanced, 8Ω, 25V, and 70.7V
Zone 2- 8Ω Unbalanced 1 watt
Zone 2- 600Ω Balanced 1.5V
OUTPUT REGULATION
Less than 2dB, no load to full load
SIGNAL TO NOISE RATIO
Mic >55 dB
Line >55 dB
Telephone >55 dB
Input 2/3 >75 dB
TONE CONTROLS
Bass ±10 dB @ 100 Hz
Treble ±10 dB @ 10 kHz
INDICATORS
Power, signal, peak
POWER CONSUMPTION
200 watt
HEIGHT
2 RU, 3.66" (94 mm)
WIDTH
8.27" (210 mm)
DEPTH
10.87" (276 mm)
