Atlona AT-HDRP User Manual

2
FEATURES
PACKAGE CONTENTS
 Silicon Image Chip-Sets allow 99.99% compatibility with all the AV gear (we only use Best)
 HDMI 1.3c compliant
 HDCP compliant
 Regenerates the HDMI signal, so there is no signal loss
 Supports Analog and Digital Audio
 Supports default HDMI EDID and has the ability to learn the EDID of displays
 Extends up to 60m (200ft) (720p / 1080i) of output CAT5/6 cable
 Extends up to 40m (130ft) (1080p) of output CAT5/6 cable
 Minimizes the cable skew by adjustable 8-level equalization control
 Pure unaltered uncompressed 7.1ch digital HDMI over CAT5/6 cable transmission
 Allows cascading
 Compatible with different receiver options: AT-HDRS and AT-HD50RSL
Note: Atlona recommends to use Cat6 or Cat5e cables for better performance. Atlona
recommends to always use "Type B" termination for the Cat6 or Cat5 Cables to extend
the distance.
AT-HD50SS
 1x AT-HD50SS unit
 1x 5V DC locking power supply unit (universal)
 1x User's manual
AT-HD50RSL
 1x AT-HD50RSL unit
 1x 5V DC locking power supply unit (universal)
 1x User's manual
