13
5. TECHNICAL SPECIFICATIONS
Model : TH135-01
Power supply : 2 AA size alkaline batteries
Max. resistive load : 5A @ 30 VAC
5A @ 30 Vdc
Max. inductive load : 2A @ 30 VAC
2A @ 30 Vdc
Auxiliary input : 12 Vcc, +/- 10 %, 2.5 mA
(telephone interface)
Control device : Electronic
Automatic action: Type 1 B
Storage temperature : -20 °C to 50 °C (-4 °F to 122 °F)
Operating temperature : 0 °C to 50 °C (32 °F to 122 °F)
( 95 % relative humidity without condensation )
Temperature setting range in heating : 5° C to 30 °C (40 °F to 85 °F)
Temperature display scale : 0.1 degree
Temperature reading accuracy : +/- 0.5 °C (+/- 0.9 °F)
Software : class A
Insulation : class
Protection degree: IP 20
The terminals are designed for a range up to 2.5 mm
2
of conductors’section.
14
WARRANTY
This product is guaranteed against workmanship defects for a two-year period
following the initial date of purchase in an authorized retail store. During this period,
AUBE technologies inc. will repair or replace, at its option and without charge, any
defective product which has been used under normal conditions.
The warranty does not cover delivery costs and does not apply to products badly
installed or damaged by accident.
This warranty cancels and replaces any other manufacturer's express or tacit
warranty as well as any other company commitment. AUBE technologies inc.
cannot be held liable for related or random damages following the installation of this
product.
The defective product as well as the purchase invoice must be returned to the place
of purchase or mailed, prepaid and insured, to the following address:
AUBE TECHNOLOGIES INC.
SERVICE CENTER
705, Montrichard
Iberville (Quebec)
Canada J2X 5K8
Tel. : (450) 358-4600
Fax : (450) 358-4650
www.aubetech.com
service@aubetech.com
18/10/02 920-135-005-00-1-A
