Page #14 background imageLoading...
Page #14 background image
What we ask from you
You will be responsible for shipping or transportation charges directly to Audioengine or to anauthorized dealer. We
recommend you keep the original shipping materials, as it is important that you package the product so that it will not
be damaged during shipping. Audioengine cannot be responsible for any damages incurred during shipping due to
poor packing, so please pack well and insure your shipment.
How to obtain Audioengine Warranty service
If you have any questions about your warranty coverage or you think you may need service, email the Audioengine
Authorized Service Center at: support@audioengineusa.com or call toll-free in the United States: (877) 853-4447.
We will do everything we can to answer your questions and resolve any issues as quickly as possible.
Exclusive Remedy
This Limited Warranty is fully transferable provided that the current owner furnishes the original proof of purchase
and that the serial number on the product is intact. THE MAXIMUM LIABILITY OF AUDIOENGINE SHALL NOT
EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT. IN NO EVENT SHALL
AUDIOENGINE BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES.
Product Returns and Refunds
Your satisfaction is guaranteed! Should you have a problem or are not satisfied with any Audioengine
product, send us an email at: support@audioengineusa.com or call toll-free in the United
States: (877) 853-4447.
A5+ Classic Quick Setup
Step 1 – Speaker Placement
Although your Audioengine 5+ speakers are very forgiving with regards to placement, it’s true that proper speaker
placement can have an impact on sound quality. There seem to be different theories on correct speaker placement
but rooms and tastes are different so it’s difficult to recommend a perfect setup. We do suggest you feel free to
experiment to see what works for you. As a general rule of thumb for the best soundstage and imaging, the
speakers should be equidistant from side walls and a different distance from rear walls. Tweeters should be at about
eye-level in your most frequent listening location and for the best bass response we recommend at least 6 inches of
clearance between the rear of the speakers and the wall behind them. Here are a few more suggestions, assuming
you have some exibility regarding where you place your speakers. No need for concern if your situation and listening
environment dictate the speakers’ position.
Both speakers should be equidistant from your primary listening position.
Placing the speakers at least 6 feet (1.8m) apart usually provides the best imaging.
Try to keep the speakers near the front edge of shelves or cabinets.
Allow at least 6 inches of clearance between the rear of the speakers and the wall or surface behind them.
If you need to turn the speakers on their sides, position the tweeters toward the outside.
If used on a desktop for computer speakers, it’s best if they are placed on a solid surface
Step 2 – Connecting the Speaker Wire
The Audioengine 5+ speakers have amplifiers built into the left cabinet and the included speaker wire is used to
connect both speakers to each other. The A5+ uses high quality, ve-way gold plated binding posts that will accept
heavy gauge bare wire, banana plugs, spade lugs, or pin terminators.

Other manuals for AudioEngine A5+

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AudioEngine A5+ and is the answer not in the manual?

AudioEngine A5+ Specifications

General IconGeneral
Product colorWhite
Housing material-
Recommended usageUniversal
Remotely operatedYes
Suitable for outdoor useNo
Magnet typeNeodymium
Tweeter diameter20 mm
Speaker placementTabletop/bookshelf
Audio output channels2.0 channels
Woofer diameter (imperial)5 \
Amplifier classA/B
Impedance- Ω
Frequency range50 - 22000 Hz
RMS rated power50 W
Signal-to-Noise Ratio (SNR)95 dB
Peak Music Power Output (PMPO)150 W
Total Harmonic Distortion (THD)0.05 %
Cables includedAC, Audio (3.5mm)
Connectivity technologyWired
AC input voltage115 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)4 W
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width180 mm
Height270 mm
Weight11400 g
