AUX ALCA-H**R1AA User Manual

AUX-Light CAC 50Hz R410A Trouble shooting
89
2. Capacity Amendment
2.1 Amendment coefficient of cooling capacity under different indoor/outdoor DB and WB
temperature
Indoor air inlet
temperature°C
Outdoor air inlet DB temperature°C
DB
WB
25
30
35
40
43
45
47
49
23
16
0.98
0.94
0.89
0.85
0.82
0.79
0.74
0.71
25
18
1.05
1
0.95
0.90
0.87
0.82
0.77
0.72
27
19
1.1
1.05
1
0.95
0.91
0.87
0.84
0.79
28
20
1.12
1.07
1.02
0.96
0.93
0.90
0.86
0.81
30
22
1.19
1.13
1.08
1.02
0.99
0.96
0.91
0.88
32
24
1.26
1.20
1.15
1.08
1.05
1.02
0.97
0.92
Actual cooling capacity calculation:
Actual cooling capacity=amendment coefficient of cooling capacity × nominal cooling capacity
——nominal cooling capacity could be found from the performance parameters list
——amendment coefficient of cooling capacity could be found from table above.
2.2 Amendment coefficient of heating capacity under different indoor/outdoor DB and WB
temperature
Actual heating capacity calculation:
Actual heating capacity=amendment coefficient of heating capacity × nominal heating capacity
——nominal heating capacity could be found from the performance parameters list
——amendment coefficient of heating capacity could be found from table above.
Indoor air inlet DB
temperature°C
Outdoor air inlet WB temperature°C
-15
-10
-5
0
6
10
15
16
0.45
0.53
0.65
0.80
1.02
1.13
-
18
0.47
0.55
0.61
0.76
1.02
1.12
-
20
0.46
0.54
0.6
0.75
1
1.11
1.25
21
0.42
0.49
0.59
0.72
0.99
1.1
1.24
22
0.41
0.49
0.58
0.71
0.97
1.09
1.23
24
0.39
0.45
0.56
0.7
0.96
1.08
1.22
