 Model Numbers
Model number Description
RJ-1 Basic model number for Advanced Remote I/O Module
101 W 1600 16 digital inputs, power: 100–240 V AC
102 W 1600 8 digital inputs + 8 digital outputs, power: 100–240 V AC
103 W 0400 4 universal I/Os (UIO)
*
, power: 100–240 V AC
* The universal I/O (UIO) can be connected to the Advanced Controller for Chiller Units, Advanced Controller for Pump Units, and model
WJ-1103 Advanced ontroller .
When installing an isolator externally, it is possible to allocate an isolator for 2 terminals (voltage input + voltage input) or 2 terminals
(current input + current input) per 1 terminal block.
z Optional parts
Model number Description
83104567-001 DIN rail clamp
z Optional parts (for CE marking)
Model number Description Remarks
8310 4611- 0 02
• EMC lter
• Accessory (180 mm cable with modular plug)
When it is necessary to comply with CE
marking
z Replacement parts
Model number Description
83173707-001 Power connector (× 1)
