78
SECTION 6. CARE AND MAINTENANCE
WARNING:
Turn the power switch off and unplug the machine before
cleaning.
NOTE:
Do not dismantle the machine in any way other than
what is explained in this section.
Clean the outside of the machine with a soft damp cloth
and mild soap.
Cleaning the Hook Race and Feed Dogs
z Remove the presser foot and needle. Remove screw
on the needle plate with the screwdriver.
Remove the needle plate and take out the bobbin.
q Screw
x Lift up the bobbin holder and remove it.
w Bobbin holder
c Brush out dust and lint. Wipe the bobbin holder with a
soft, dry cloth.
v Clean the feed dogs and hook race with the lint
brush.
e Lint brush
r Feed dogs
b Wipe the hook race with a soft, dry cloth.
t Hook race
NOTE:
You may also use a vacuum cleaner.
z
x
c
v
b
q
w
e
r
t
