Baby Lock Molly BL30A User Manual

80
Replacing the Bobbin Holder
z Insert the bobbin holder into the hook race.
x Make sure the knob of the bobbin holder fits next to
the stopper on the race.
q Knob
w Stopper
c Replace the bobbin.
Attach the needle plate, inserting the two guide pins
into the holes in the needle plate. Tighten the screw
firmly with the screwdriver.
e Guide pin holes
r Screw
Replacing the Light Bulb
WARNING:
When replacing the bulb, switch off and unplug the
machine.
Wait for the light bulb to cool down before touching it.
Remove the cap and screw. Remove the face plate.
q Cap
w Screw
e Face plate
Push in and turn the bulb clockwise to remove it.
Push in and turn the bulb counterclockwise to replace it.
r Light bulb (bayonet type —120V-15W)
q
w
e
r
e
q
w
e
r
z
x
c
