Baxi 720030501 User Manual

11
© Baxi Heating UK Ltd 2009
6.0 Batteries & Specification
6.1 Low Battery (Fig. 21)
1.When the Battery Level symbol is
displayed the batteries should be changed
within 3 months.This symbol will appear
ONLY when the batteries are low.
6.2 Transmitter Specification
• Batteries:- 2 x LR03 or AAA 1.5V
• Class III insulation
• 868 MHz transmission frequency
• IP 30 Protection
• Operation temperature 0°C to +40°C
6.3 Receiver Specification
• 240V ac 50 Hz (+/- 10 %) power supply
• Class II insulation
• 868 MHz transmission frequency
• IP 44 - IK 04 Protection
• Operation temperature -5°C to +50°C
Battery level
symbol
Fig. 21

Baxi 720030501 Specifications

General

Brand	Baxi
Model	720030501
Category	Thermostat
Language	English
