P.4F0 – safety input SE2
Function Profile Description Testing
0.XX
No function
No function
0.00 -
3.XX
Wicket door
Adjustment with an 8k2 resistor (e.g. Vitector ENS-S 8200) is recommended (factory set-
ting) to achieve safe operation according to EN 12453. If the door is open, travel is not
possible. If the door is not in the CLOSE limit position, the error code F.214 appears.
When evaluating a wicket door switch and a slack rope switch with cable monitoring 5k1,
the profile 3.03 must be used.
3.00 8k2 ohm Internal testing
3.01 NC – normally closed Without testing
3.02 NC – normally closed External testing
3.03 5k1 Ohm Internal testing
4.XX
Electric safety edge 2
The door stops when this is activated. Reversal and the operating direction are dependent
on P.4F4.
4.00 8k2 Ohm Without testing
4.01 1k2 Ohm Without testing
4.02 8k2 ohm, DW edge CLOSE limit position,
after pre-limit-switch
4.03 1k2Ohm, DW edge CLOSE limit position,
after pre-limit-switch
4.04 Safety device with PNP output External testing
4.05 Safety device with NPN output External testing
Function inputs FE
The inputs FE1-FE14 can be freely parameterised for external control sensors, for example.
Various functions can be assigned to the inputs. One function can have various parameters. Function and parameter are shown at
the same time on a combined display.
Some functions can only be selected once.
For installation of the inputs, any existing jumpers must be removed.
NC – normally closed contact type: The function is activated by opening the input.
NO – normally open contact type: The function is activated by closing the input.
Input profiles table
The following functions and parameters can be assigned to the inputs.
Function Profile Description
0.XX
No function
No function
0.00 -
5.XX
Optoelectronic safety
edge OSE – only at FE1
Evaluation of a safety element with an OSE signal.
5.00 Safety in CLOSE | With reversal
5.01 Safety in OPEN | No reversal
5.02 Safety in OPEN and CLOSE | Stop function, dead-man travel possible
5.03 Safety in OPEN and CLOSE | Stop function, no travel possible
6.XX
OPEN limit position –
firmly set to FE7
Mechanical limit switching – OPEN limit switch
6.00 NC – normally closed
6.01 NO – normally open
7.XX
CLOSE limit position –
firmly set to FE8
Mechanical limit switching – CLOSE limit switch
7.00 NC – normally closed
7.01 NO – normally open
20
