BECKHOFF Drive Technology 4 Product description
AX5000 Version : 4.5 17
4.4 Technical data
UL-Listing!
It is essential to observe chapter 3.3 if you wish to operate an AX5000 in
USA or Canada.
4.4.1 Permissible ambient and operating conditions
Ambient / operating conditions
Permissible values
Ambient temperature during operation
0 °C to +50 °C
Ambient temperature during transport /
storage
-25 °C to +70 °C
Air humidity
5 % to 95 %, non-condensing
Pollution degree
2 according to EN 60204/EN 50178
Corrosion protection
Normally not required.
Under extreme operating conditions separate
measures must be agreed with the manufacturer.
Operating altitude
up to 1000 m above sea level
Installation position
vertical
Ventilation
Total device current ≤ 3 A: free convection
Total device current > 3 A: built-in temperature-
controlled fan
Protection class
IP 20
Vibration test (EN 60068-2-6)
Frequency range: 10-500 Hz
Amplitude: 10-58 Hz = 0,075 mm pk-pk
59-500 Hz = 1 g
Shock test (EN 60068-2-27)
Half sine wave amplitude: 5 g
Duration: 30 ms
Number of shocks: 3 per axis and direction
(total 18)
Repetitive shock test (EN 60068-2-27)
Half sine wave amplitude: 5 g
Duration: 30 ms
Number of shocks: 1000 per axis and direction
(total 6000)
EMC
Category C3 - standard
Category C2, C1 - auxiliary filter required
4.4.2 Electrical data - single-channel servo drive (AX51xx)
4.4.2.1 Single-phase connection
Electrical data
AX5101
AX5103
AX5106
Rated output current
1.5 A
3 A
4.5 A
Minimum channel current at full current
resolution
0.35 A 1 A 1 A
Max. output current
(1)
4.5 A
7.5 A
13 A
Rated supply voltage
1x 100
-10%
– 240
+10%
V
AC
Max. DC link voltage
890 V
DC
Rated apparent power
