Specications
X1832USB X1222USB
Mono Inputs
Microphone Inputs
(XENYX Mic Preamp)
6
Type XLR connector, electronically balanced, discrete input circuit
Mic E.I.N.1 (20 Hz - 20 kHz)
@ 0 Ω source resistance -134 dB 135.7 dB A-weighted
@ 50 Ω source resistance -131 dB 133.3 dB A-weighted
@ 150 Ω source resistance -129 dB 130.5 dB A-weighted
Frequency response (-1 dB) <10 Hz - 150 kHz (-1 dB)
Frequency response (-3 dB) <10 Hz - 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB GAIN
Impedance 2.6 k Ohms balanced
Signal-to-noise ratio
110 dB A-weighted
(0 dBu In @ +22 dB GAIN)
Distortion (THD + N) 0.005% / 0.004% A-weighted
Phantom Power Switchable, +48 V
Line Input
Type ¼" TRS jack, electronically balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -10 dB to +40 dB
Max. input level 30 dBu
Frequency Response (Mic In -Main Out)
<10 Hz - 90 kHz +0 dB / -1 dB
<10 Hz - 160 kHz +0 dB / -3 dB
Stereo Inputs
Type 4 dual ¼" TRS jacks, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu
2-TRACK/USB Input
Type RCA connector
Impedance 10 k Ohms
Max. input level +22 dBu
Equalizer 3-band Equalizer 3-band semi-parametric
LOW 80 Hz / ±15 dB
MID
Variable
100 Hz - 8 kHz / ±15 dB
2.5 kHz / ±15 dB
HIGH 12 kHz / ±15 dB
Equalizer 4-Band Fixed
LOW 80 Hz / ±15 dB —
LOW MID 500 Hz / ±15 dB —
HIGH MID 3 kHz / ±15 dB —
HIGH 12 kHz / ±15 dB —
Channel Inserts
Type 6 x ¼" TRS jacks, unbalanced
4 x ¼" TRS jacks,
unbalanced
Max. input level +22 dBu
X1832USB X1222USB
AUX Sends/Mon
Type
3 x ¼" mono jack,
unbalanced
2 x ¼" mono jack,
unbalanced
Impedance 120 Ohms
Max. output leve +22 dBu
AUX Returns
Type 2 dual ¼" TRS connectors, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Max. input level +22 dBu
Main Outputs
Type
XLR, ¼",
electronically balanced
XLR,
electronically balanced
Impedance 240 Ohms balanced, 120 Ohms balanced
Max. output level +28 dBu
Control Room Output
Type ¼" TS connector, unbalanced
Impedance 120 Ohms
Max. output level +22 dBu
Phones Output
Type ¼" TRS jack, unbalanced
Max. output level +19 dBu / 150 Ohms (+25 dBm)
2-TRACK/USB Output
Type RCA connector
Impedance 1 k Ohms
Max. output level +22 dBu
DSP
Converter 24-bit Delta-Sigma 64/128-times oversampling
Sampling Rate 40 kHz
Main Mix System Data (Noise)
Main mix @ -∞,
channel fader @ -∞
-105 dB / -108 dB A weighted
Main mix @ 0 dB,
channel fader @ -∞
-95 dB / -97 dB A weighted
Main mix @ 0 dB,
channel fader @ 0 dB
-82.5 dB / -85 dB A weighted
Power Supply
Mains voltage 100 - 240 V~, 50/60 Hz
Power consumption 50 W 40 W
Fuse (100 - 120 V~, 50/60 Hz) T 1,6 A H 250 V
Fuse (220 - 230 V~, 50/60 Hz) T 1,6 A H 250 V
Mains connector Standard IEC receptacle
USB
Audio Stereo In/Out
Connector Type B
Converter 16-bit
Sample Rate 48 kHz
Physical/Weight
Dimensions (H x W x D)
3.54 x 16.93 x 14"
90 x 430 x 355 mm
3.54 x 14.57 x 13"
90 x 370 x 330 mm
Weight 10.9 lbs / 4.9 kg 9.3 lbs / 4.2 kg
