Page #2 background image
2
A d.c. motor (9) drives the eccentric (5) with the bearing (6)
continuously. The eccentricity effects the prime- and
pressure stroke of the delivery piston (7), whereby the
integrated non-return valve (8) prevents the medium from
being reprimed into the main line.
The agitator blade (2) presses the lubricant out of the
supply container (1), through a screen (4), which reduces
air inclusions, into the suction area in the pump housing (3).
A scraper at the agitator blade (2) enables a visual control
of the existing grease level in the transparent reservoir (1).
Multi line pump OC-1
Function
Subject to alterations!
1
5
9
2
4
7
8
6
3
...een product van BEKA
