Benelli TRK 702X User Manual

3 - 18
Instrument and control functions
EN
3
Seats
Passenger seat
To remove the passenger seat:
1. Insert the key into the seat lock, and
then turn it clockwise.
1
1. Seat lock
2. Lift the front side of the passenger seat
and pull it forward.
To install the passenger seat
1. Insert the projections on the rear side of
the passenger seat into the relevant hol-
ders and then push the front side of the
seat downwards to lock it in place.
Rider seat
To remove the rider seat
1. Pull the knob (1)
2. Lift the back of the rider seat and pull it
backward.
1
To install the rider seat
1. Insert the projection on the front side of
the rider seat into the relevant holder, and
then push the back of the seat downward
to lock it in place.
Adjusting the headlight beams
The headlight beam adjusting knob is
used to raise or lower the height of the
headlight beam. It may be necessary to
adjust the headlight beam to increase
visibility and help prevent blinding onco-
ming drivers when carrying more or less
load than usual.
Follow local laws and regulations when
adjusting the headlights.
To raise the headlight beam, turn the
knob anticlockwise.
To lower the headlight beam, turn the
knob clockwise.
