5) PARAMETERS, LOGICS AND SPECIAL FUNCTIONS
In the tables hereunder the single functions available in the control unit are shown.
5.1) PARAMETERS (PAR)
MENU FUNCTION MIN-MAX-(Default) MEMO
TCA
Automatic closure time. It is activated only with “TCA”=ON logic.
At the end of the preset time, the control unit controls a closure operation.
1-240-(40s)
TM
Motor operating time. The total stroke time in the motor opening and closing phases is adjusted.
With the ENC:ON logics, this value is automatically preset by the parameter self-adjustment
procedure (AUTO).
2-180-(60s)
Tsmo
The space covered by the dooe leaf during braking in the opening phase is adjusted. 0 = braking
is disabled.
The value is expressed in percentage on the aggregate value of the stroke.
With ENC:OFF logics the value is expressed in seconds. Braking after the triggering of the limit
switch is adjusted.
0-10-(0%)
Tsmc
The space covered by the dooe leaf during braking in the closing phase is adjusted.
0 = braking is disabled.
The value is expressed in percentage on the aggregate value of the stroke.
With ENC:OFF logics the value is expressed in seconds. Braking after the triggering of the limit
switch is adjusted.
0-99-(0%)
Pso
The torque applied to the motor during braking in the closing phase is adjusted.* 30-99-(50%)
Psc
The torque applied to the motor during braking in the opening phase is adjusted * 30-99-(50%)
TLS
The activation time of the service light is adjusted.
With parameter :0, the area light function is activated. The light is switched on when the motor is
moving and during the TCA dwell time. The light switches off when the motor stops.
0-240-(60s)
SEAV
The triggering threshold of the anti-crash device (Encoder) during the normal speed phase.*
99: maximum sensitivity - 0: minimum sensitivity
0-99-(0%)
SEAR
The triggering threshold of the anti-crash device (Encoder) during braking.*
99: maximum sensitivity - 0: minimum sensitivity
0-99-(0%)
AUX
The operating mode of the auxiliary output to terminals 19/20 is preset. See wire connections in
figure 2.
0: output configurated as SCA (open gate indicator light): Off with closed door, on with open
door, slow flash during opening, rapid flash during closing.
1: output configurated as radio channel II integrated receiver.
2: output configurated as PHOT TEST (photocell test).
3: output configurated as flashing light.
4: output configurated as service light additional to the light on the geared motor. Its activation
time is adjusted by TLS parameter.
0-4-(0)
* WARNING:
An incorrect setting of these parameters may cause danger.
Please comply with regulations in force!
5.2) LOGIC (LOG)
MENU FUNCTION
ON-OFF-
(Default)
MEMO
TCA
The automatic closure is enabled or disabled
On: enabled automatic closure
Off: disabled automatic closure
(OFF)
IbL
The multi-flat function is enabled or disabled.
On: enabled multi-flat function. The P.P. (Step-by-step) impulse or the impulse of the transmitter have
no effect in the opening phase.
Off: disabled multi-flat function.
(OFF)
PP
The operating mode of “P.P. Push button” and of the transmitter are selected.
On: Operation : OPEN > CLOSE > OPEN >
Off: Operation: OPEN > STOP > CLOSE > STOP >
(OFF)
PRE
Forewarning flashing light enabled or disabled.
On: enabled forewarning flashing light. The flashing light is activated 3 s before the starting of the
motor.
Off: disabled forewarning flashing light.
(OFF)
blc
The lock function in the closing phase is enabled or disabled.
On: Lock function is enabled.
Off: Lock function is disabled.
(ON)
ltca
During the TCA time, the blinker is enabled or disabled.
On: Activated blinker.
Off: De-activated blinker.
(OFF)
