BERJAYA Display Chiller User Manual

COMPONENT LIST (SENARAI KOMPONEN)
1D/MDC-SM 1D/DC-SM-AL 2D/DC-SM-AL 3D/DC-SM-AL
1D/DC-MG 2D/DC-MG 3D/DC-MG
1D/DC-SM 2D/DC-SM 3D/DC-SM
GS-M1155-MD GS-M1155-DC GS-M1155-DC GS-M1155-DC
562mm x 1158mm 584mm x 1410mm 584mm x 1410mm 584mm x 1410mm
CC-14UR CC-14UR CC-24UR CC-34UR
- CC-16HH CC-24HH CC-34HH
G-DCG-L G-DCG-L G-DCG-L
G-DCG-R G-DCG-R G-DCG-R
527mm X 1125mm 550mm X 1383mm 550mm X 1383mm 550mm X 1383mm
Left (Kiri) GC-SDCH-MG-LG GC-SDCH-MG-LG GC-SDCH-MG-LG
Right (Kanan) GC-SDCH-MG-RG GC-SDCH-MG-RG GC-SDCH-MG-RG
Dimension 582mm X 1180mm 605mm X 1438mm 605mm X 1438mm 605mm X 1438mm
Left (Kiri) GC-SDCH-SM-LG GC-SDCH-SM-LG GC-SDCH-SM-LG
Right (Kanan) GC-SDCH-SM-RG GC-SDCH-SM-RG GC-SDCH-SM-RG
Dimension 582mm X 1180mm 605mm X 1438mm 605mm X 1438mm 605mm X 1438mm
NT-3D-DC-M
525mm X 597mm
NT-2/3D-DC-S
525mm x 546mm
Gold (Emas) CS-PN-MC-LB-G CS-PN-1C-LB-G CS-PN-2C-LB-G CS-PN-3C-LB-G
Silver (Perak) CS-PN-MC-LB-S CS-PN-1C-LB-S CS-PN-2C-LB-S CS-PN-3C-LB-S
Black (Hitam) CS-PN-MC-LB-B CS-PN-1C-LB-B CS-PN-2C-LB-B CS-PN-3C-LB-B
Left (Kiri) - DR-07HGLH DR-07HGLH
Right (Kanan) - DR-08HGRH DR-08HGRH DR-08HGRH
Swivel (Putar) WL-NS2 WL-PUS4-BLK-E WL-PUS4-BLK-E WL-PUS4-BLK-E
Brake (Brek) - WL-PUB4-BLK-E WL-PUB4-BLK-E WL-PUB4-BLK-E
PVC-AS1D/MDC PVC-AS1D/D PVC-AS2D/D PVC-AS3D/D
580mm X 123mm 625mm X 300mm 1250mm X 300mm 1860mm X 300mm
Gold (Emas) OP-AP-1C-DF-G OP-AP-2C-DF-G OP-AP-3C-DF-G
Silver (Perak) OP-AP-1C-DF-S OP-AP-2C-DF-S OP-AP-3C-DF-S
Black (Hitam) OP-AP-1C-DF-B OP-AP-2C-DF-B OP-AP-3C-DF-B
(SM - Display Chiller / REV 01 / 2019 / 02)
6
No
Model (Model)
1D/MDC-MG
Parts (Bahagian)
1
Compressor (Pemampat)
(1/6 HP)
(1/4 HP)
(2/5 HP)
(1/2 HP)
2
Fan Motor (Motor Kipas) - Condenser
FE-VDE10W
FE-VDE10W
FE-VDE10W
FE-VDE25W
3
Door Gasket (Gasket Pintu)
4
Condenser (Kondenser)
CD-025-3
CD-033-3
CD-060-3
CD-85A-3
5
Cooling Coil
Standard (Piawai)
(Lingkaran Penyejukan)
High Humidity (Kelembapan Tinggi)
6
Fan Motor (Motor Kipas) - Cooling Coil
FE-LUVE10W
FE-LUVE10W
FE-LUVE10W
FE-LUVE10W
7
Digital Thermometer - Dixell (Termometer Digital - Dixell)
TM-Y134
TM-XR30CX-B-1
TM-XR30CX-B-1
TM-XR30CX-B--1
8
Door Glass Only - Anti-Mist (Kaca Pintu Sahaja - Anti Kabus)
G-MDC
Door - Complete Set - Gold (Pintu - Set Lengkap -
Emas)
GC-MDGD-MG-RG
Door - Complete Set - Silver (Pintu - Set Lengkap -
Perak)
GC-MDGD-SM-RG
9
Shelving (Talam)
NT-MDC-1D
NT-1D-DC
NT-2/3D-DC-S
476mm X 400mm
525mm X 501mm
525mm x 546mm
10
Light Box (Kotak Lampu)
11
Shelving Clips (Klip Tingkat - Alas)
HW-BSP14W
HW-BSP14W
HW-BSP14W
HW-BSP14W
12
Door Spring (Spring Pintu)
-
DR-12
DR-12
DR-12
13
Lower Fulcrum Bolt (Skru Fulkrum Bawah)
-
DR-04L-BOLT
DR-04L-BOLT
DR-04L-BOLT
14
Door Hinges (Engsel Pintu)
15
Wheel (Roda)
16
PVC Acrylic Sheet (Akrilik Lembaran PVC)
17
Display Chiller Digital Frame (Penyejuk Peti Pamer
Digital Frame)
-
18
Display Down Panel C/B - Complete Set (Peti Pamer Panel Bawah
C/B - Set Lengkap)
-
CS-PN-D1D-DP
CS-PN-D2D-DP
CS-PN-D3D-DP
19
Fan Cover - Complete Set (Penutup Kipas - Set Lengkap)
CS-FC-4X1M-CB
CS-FC-8X1-CB
CS-FC-8X1-CB
CS-FC-8X2-CB
