Bernina BERNETTE 80e User Manual

58
For straight stitch select pattern “ “ with
pattern selector dial. Adjust the stitch
length with the stitch length dial. You may
choose any needle position from center to
left, by turning the stitch width dial.
For zigzag stitch
, select pattern “ “ with
pattern selector dial. Adjust the stitch
length and stitch width according to the
fabric being used.
To obtain any of the other patter
ns shown
in the upper row on the stitch selection
panel, select the pattern with the pattern
selector dial. Adjust the stitch length and
the stitch width with the control dials
according to the result desired. (see Quick
reference draw)
To obtain any of the patter
ns on the
second row
, turn the stitch length dial to
“S”, select the pattern desired with pattern
selector dial, and adjust the stitch width
with the stitch width dial. (model 80e/90e)
How to choose your
pattern
EN
60
Outline of LCD information (1)
a. Stitch width
b. Stitch length
c. Presser foot
d. Stitch pattern and figure
Example stitch number “02” (2)
A - Regular setting
· Pattern: straight stitch
· Recommended length: “2.5” ~ “4”
· Recommended needle position (stitch
width dial): “0” ~ “7”
· Recommended presser foot: “C”
B - S setting
· Pattern: triple stretch stitch
· Stitch length: “S”
· Recommended needle position (stitch
width dial): “0” ~ “7”
· Recommended presser foot: “C”
LCD (Liquid crystal display)
EN

Bernina BERNETTE 80e Specifications

General

Number of Stitches	80
Buttonhole Styles	7
Maximum Stitch Width	7 mm
Needle Threader	Yes
Speed Control	Yes
Start/Stop Button	Yes
Needle Stop Up/Down	Yes
Stitch Length	4 mm
Drop Feed	Yes
LED Lighting	Yes
Type	Electronic
Presser Feet	Included
