Bestway LAY-Z-SPA MIAMI User Manual

INSTALLATION INSTRUCTIONS
2. Outdoor Installation:
• During filling, draining or when in use, water may flow out of
the spa. Therefore the Lay-Z-Spa should be installed near a
floor drain.
• Do not leave the spa's surface exposed to direct sunlight for
long periods of time.
WARNING: TO AVOID
ELECTRIC SHOCK, DO NOT
USE THE SPA WHEN IT IS
RAINING.
1. Indoor Installation:
Be aware of special requirements if you install the spa
indoors.
• Humidity is a natural side effect with Lay-Z-Spa
installation. Determine the effects of airborne moisture on
exposed wood, paper, etc. in the proposed location. To
minimize these effects it is best to provide plenty of
ventilation to the selected area. An architect can help
determine if more ventilation is needed.
Selected Location
WARNING: The selected location has to be able to support of supporting the
expected load.
WARNING: An adequate drainage system has to be provided to deal with overflow
water for both indoor and outdoor installations.
IMPORTANT: Because of the combined weight of the Lay-Z-Spa, water, and users, it
is extremely important that the base where the Lay-Z-Spa is installed is smooth, flat,
level and capable of uniformly supporting the weight for the entire time the Lay-Z-Spa
is installed (not on the carpet or other similar material). If the Lay-Z-Spa is placed on
a surface, which does not meet these requirements, any damage caused by
improper support is not covered under the manufacturer’s warranty. It is the
responsibility of the Lay-Z-Spa owner to assure the integrity of the site at all times.
Part N. Part Code Description QTY
001 54129TASS15 Pool 1
002 P4B079ASS15 Heater 1
003 P5B401ASS15 Top Leatheroid Cover 1
004 54129GASS15 Inflatable
Part Top Cover 1
005 P6930 Inflation Hose 1
006 P6653 Filter Set 1
007 58210S10
58321(H) S15
P6933
Chemical Floater 1
008 Ground mat 1
009 F6H189 Wrench 1
010 P6575 Stoppers 2
011 P6H565 Hose Adapter 1
012 Pressure Gauge 1
013 P6611 Cover Adapter A 1
014 P6H971 Inflation Valve
1
S-S-002097
11

Bestway LAY-Z-SPA MIAMI Specifications

General

Capacity	2-4 adults
Control Panel	Digital
Energy Saving Timer	Yes
Freeze Shield	Yes
Water Capacity	669 liters (177 gallons)
Inflated Size	1.80 m x 66 cm (71 in. x 26 in.)
Inner Size	1.32 m (52 in.)
Filled Weight	696 kg (1, 534 lbs)
Actual Water Flow	1, 325 liters/hour (350 gal./hour)
Heating Rate	1.5-2.0°C/h (3-4°F/h)
Max Temperature	40°C (104°F)
AirJets	120
Pump	Yes
Cover	Yes
Included Accessories	ChemConnect dispenser, filter cartridge (VI), repair patch
Power Supply	220-240V~50Hz, 2, 050W at 20°C
Certification	CE Approved
Material	TriTech 3-ply reinforced material
