User Manual for MT Refrigerators and Freezers Beverage-Air
Rev. 07/22Beverage-Air8
Operating Steps:
• Once equipment is in place, let stand for at least 12 hours to allow compressor oil to fully settle.
• Plug the unit into electrical outlet, following all previous instructions and electrical specications.
• Avoid operating equipment with wet hands, or in standing water to avoid electrical hazard.
Product Storage:
• Install shelves using metallic clips (make sure they are aligned at the same height).
• If the cooler has been turned o and it is necessary to turn it back on, wait at least one hour to cool the interior before
reloading product.
• When the cooler is lled up, arrange and order product inside. Do not throw or drop product into the cabinet as it may
damage the interior or shelving.
Air ow inside the cabinet is very important. Please make sure that:
• Product weight does not exert pressure on internal walls and product does not extend beyond perimeter of shelves.
• Avoid introducing products in closed boxes/cartons, trays, and/or bags sealed in plastic as it may aect actual product
temperature.
• Keep products away from fan blades. Do not obstruct fan air inlets.
IMPORTANT: Some models are designed to cool products at
temperatures below 32°F. Do not use this type of cooler for other
products that may be quality aected due to these kinds of
temperatures. Some products freeze when subjected to these
temperatures and the containers may explode. If product containers
are made of glass, they may cause lesions and serious wounds to
you; thus, always follow recommendations and instructions from
your supplier. Do not introduce unauthorized containers or product
or ask the Service Center for further details.
We recommend that you restock equipment at the end of the day
so product has a chance to cool to correct temperature by the next
business day; doing so, will also contribute to energy savings.
Always keep doors closed overnight to maintain proper temperature
and ecencies.
OPERATING EQUIPMENT
1
Angel Puente
From: Guadarrama Polo Carlos <carlos.guadarrama@imberacooling.com>
Sent: Sunday, February 20, 2022 9:37 AM
To: Angel Puente
Subject: RE: MT Manual
Attachments: 2096649MECR01.pdf
HiAngelgoodmorning
AswespokelastFriday,weagreedtomakequickchangesintheinformationyouhave.
BevAirUsermanualpt1:
1. Page1;Usermanual#3057689
2. Page4;theinformationshownisok.
3. Page5;MT21Dim=391/8”istherightwidth.Inthefollowingchartaretherefrigerantcharge.Besidesallthe
unitstemperaturerangearefrom0°Cto7°C
MT23‐1B REFRI GERANTER‐290(PROPANO) 0.055 KG
MT53‐1B REFRI GERANTER‐290(P ROPANO) 0.095 KG
MT49‐1SDB REFRI GERANTER‐290(P ROPANO) 0.085 KG
MT49‐1B REFRI GERANTER‐290(P ROPANO) 0.095 KG
MT53‐1SDW REFRI GERANTER‐290(P ROPANO) 0.095 KG
MT12‐1W REFRI GERANTER‐290(P ROPANO) 0.055 KG
MT10‐1W REFRI GERANTER‐290(P ROPANO) 0.047 KG
MT08‐1H6B REFRI GERANTER‐600A(ISOBUTANO) 0.045 KG
MT34‐1W REFRI GERANTER‐290(P ROPANO) 0.06 KG
MT21‐1B REFRI GERANTER‐290(P ROPANO) 0.065 KG
4. Removeinformationinpage6andkeeppage9.
5. Page7;UnpackingandsetupIwouldremovetheword“skid”anduse“pallet”,with thatandproperimageswill
befine.
6. Page12to16
isforTMRunitsand asIexplainedtoyouthisunitsareproducedatFERSA(ReachIns)andIdon’t
havetheinformation.Ifyouaretalkinga bo u tMTunitsmeansthatyoumayusetheinformationoftheuser
manual,(troubleshooting)andthefollowinginformationifisusefulforyouchangingImberaUSAforyour
properTechnicalServicenameplease.
7. Pages18and19areok
8. WiringdiagramofMT53hingedoorisattached
BevAirUsermanualpt2:
MODEL NUMBER MAXIMUM LOAD FOR
HORIZONTAL GRILL (lbs)
MT06
MT08 58.64
MT10 112.65
MT12 98.54
MT21 85.98
MT23 147.71
MT34 98.54
MT49 121.48
MT49-SD 115.08
MT53 131.39
MT53-SD 147.71
MTF23
MTF53
The ETC1H control in some models is also pre-congured by the manufacturer to maintain
product temperature. It does not include a display that shows temperature or alarms. If you
notice malfunctioning, please notify the Beverage-Air Technical Services Department.
Temperature level
adjustment knob
